| Structure | |
| Fiber | |
| Core diameter | 62.5 ± 3 um |
| Cladding diameter | 125 ± 2 um |
| Coating diameter | 245 ± 10 um |
| Color | Blue |
| Tight buffer | |
| Material | LSZH |
| Outer diameter | 0.9 ± 0.05 mm |
| Buffer color | Blue |
| Reinforce element | |
| Kevlar | |
| Jacket | |
| Material | LSZH |
| Wall thickness | 0.4 ± 0.1 mm |
| Outer diameter | 2.0 ± 0.1*4.0 ± 0.1 mm |
| Color | Orange |
| Printing | I-V(ZN)H 2xG62.5/125 |
| OM1 xxxxM WWNYY | |
Optics Performance | |
| Attenuation | < 1.2 dB/km @1300nm |
| < 3.2 dB/km @850nm | |
| Bandwidth | > 500 MHz·km @1300nm |
| > 200 MHz·km @850nm | |
| NA | 0.275 ± 0.015 |
Mechanical Parameter | |
| Tensile strength | > 60N Long term |
| > 30N Short term | |
| Bending radius | > 30mm Long term |
| > 15mm Short term | |
| Crush | >500 N/dm |
Climate Properties | |
Storage and transportation | -20℃ to + 60℃ |
| During installation | -10℃ to + 50℃ |
| Operation | -20℃ to + 60℃ |
| Flame Characteristic | |
Single cable vertical flammability | GB/T 18380.12-2022 |
Smoke density > 60% | GB/T 17651.2-2021 |
Absence of halogen <= 5 mg/g | GB/T 17650.1-2021 |
